ASRock H810M-H – Compact Intel LGA1851 Motherboard

The ASRock H810M-H is a compact Micro ATX motherboard designed for modern Intel desktop systems using the LGA1851 socket. Built around the Intel H810 chipset, it supports Intel Core Ultra processors from Series 2 and provides a practical foundation for gaming PCs, home computers, and productivity-focused systems. Its compact 22.0 × 19.3cm Micro ATX form factor makes it suitable for smaller cases while retaining the essential connectivity required by a modern desktop platform. The motherboard combines DDR5 memory support, PCIe 4.0 expansion, high-speed NVMe storage, Gigabit Ethernet, and integrated display connectivity. With its straightforward feature set and modern Intel platform, the H810M-H is designed for users who need a reliable and space-efficient motherboard for a current-generation PC build.

Intel LGA1851 and Core Ultra Processor Support

Designed for the Intel LGA1851 platform, the ASRock H810M-H supports Intel Core Ultra processors from Series 2. The Intel H810 chipset provides the foundation for the platform, while the motherboard also supports Intel Hybrid Technology, Turbo Boost Max 3.0, Thermal Velocity Boost, and Adaptive Boost Technology where supported by the installed processor. Compatible CPUs with integrated graphics can also take advantage of the processor's integrated visual capabilities and NPU features. The board uses a 6+1+1+1+1 power phase design, providing a suitable power delivery platform for supported processors. This combination makes the H810M-H a practical choice for compact systems using Intel's latest desktop architecture.

Dual-Channel DDR5 Memory

The motherboard features two DDR5 DIMM slots supporting dual-channel memory operation and up to 128GB of system memory. It supports DDR5 non-ECC unbuffered memory at speeds of up to 6400 MT/s, depending on the processor and memory configuration. The board also supports Intel XMP 3.0, allowing compatible memory kits to be configured using their supported performance profiles. Support for CUDIMM memory further expands compatibility with newer DDR5 memory technologies. With two memory slots, the H810M-H is particularly suitable for compact builds using common dual-module configurations such as 2×16GB or 2×32GB. Dual-channel operation provides additional memory bandwidth for everyday applications, gaming, multitasking, and other workloads that benefit from faster system memory.

PCIe 4.0 and High-Speed NVMe Storage

The ASRock H810M-H provides a PCIe 4.0 x16 slot connected to the CPU, providing the primary expansion interface for a dedicated graphics card or other compatible hardware. An additional PCIe 4.0 x1 slot is available for smaller expansion devices. Storage connectivity includes a dedicated Hyper M.2 slot supporting PCIe Gen4 x4 connectivity for compatible 2280 NVMe SSDs, providing high-speed storage performance for modern operating systems, applications, and games. The motherboard also includes four SATA3 6Gb/s connectors for additional SATA storage devices. This combination allows a compact system to use a fast NVMe boot drive while retaining multiple SATA ports for additional SSDs or hard drives.

Connectivity and Integrated Graphics

For wired networking, the H810M-H features a Realtek RTL8111H Gigabit LAN controller, supporting 10/100/1000Mb/s Ethernet connectivity. Wireless networking is not integrated, but the board provides an M.2 Key E slot for a compatible Wi-Fi/Bluetooth module, allowing wireless connectivity to be added separately. For processors with integrated graphics, the rear I/O includes an HDMI 2.1 output supporting resolutions up to 4K at 120Hz. The rear panel also provides two USB 3.2 Gen1 Type-A ports, four USB 2.0 ports, a PS/2 keyboard/mouse connector, RJ-45 LAN, and HD audio connections. This provides the essential connectivity required for a compact modern desktop system without unnecessary expansion.

Compact Micro ATX Design

With dimensions of approximately 22.0 × 19.3cm, the ASRock H810M-H uses a compact Micro ATX layout that can fit comfortably into smaller compatible PC cases. The board provides dedicated headers for CPU and chassis fans with Smart Fan Speed Control, helping manage cooling according to system requirements. It also includes one standard RGB header and two addressable LED headers for compatible lighting components. Internal connectivity includes a 24-pin ATX power connector, 8-pin 12V CPU power connector, front-panel audio, USB 2.0 and USB 3.2 Gen1 headers, and TPM connectivity. With DDR5 support, PCIe 4.0 expansion, Gen4 NVMe storage, Gigabit Ethernet, and LGA1851 compatibility, the H810M-H provides a compact and practical foundation for modern Intel PC builds.
